Strassmayr MaxBatch

Highest quality of asphalt mixture paired with exceptional economy and performance

The MaxBatch asphalt batching plants are the most convenient solution on the market. Strassmayr put large focus on the economical aspects of everyday use: energy consumption and reliability. Our innovative approach consists of a special drying drum, which shares it’s functionality together with a double screening system. This allows to save energy and lower the daily costs of production and maintenance, while keeping the highest quality of the final product. All of the automatic plant processes are blended together by one containerized control center with a user friendly operating system. Modular construction ensures quick setup and relocation, while additional weatherproof cladding protects the structure against winter, vandalism and theft. All of the cabling between the modules is plug&play in order to decrease the erection time. MaxBatch plants are offered in 4 main capacities: 140 TPH, 180 TPH, 240 TPH and 260 TPH. Wide range of optional equipment is available, including: containerised thermal oil heating systems, RAP/Hot RAP attachments, SMA/Viatop, dye dosing systems, different solutions for hot storage silos, foreign filler systems and many more!

Strassmayr
Max Batch 100

Strassmayr
Max Batch 140

Strassmayr
Max Batch 180

Strassmayr
Max Batch 240

Capacity 100 t/h	Capacity 140 t/h	Capacity 180 t/h	Capacity 240 t/h
6 aggregate cold bins	6 aggregate cold bins	6 aggregate cold bins	6 aggregate cold bins
Drying/screening drum	Drying/screening drum	Drying/screening drum	Drying/screening drum
5 hot mineral bins	5 hot mineral bins	5 hot mineral bins	5 hot mineral bins
Twin-shaft pugmill mixer, with capacity 1500 kg	Twin-shaft pugmill mixer, with capacity 2000 kg	Twin-shaft pugmill mixer, with capacity 2500 kg	Twin-shaft pugmill mixer, with capacity 3000 kg
–	Ready mix silo 50 t, placed below the mixer	Ready mix silo 80 t, placed below the mixer	Ready mix silo 100 t, placed below the mixer
2 bitumen tanks 40 000 l	2 bitumen tanks 40 000 l	3 bitumen tanks 40 000 l	3 bitumen tanks 40 000 l
Thermal oil heating system	Thermal oil heating system	Thermal oil heating system	Thermal oil heating system
Foreign filler silo 50 t.	Силос для привозного заполнителя емкостью 100 т	Силос для привозного заполнителя емкостью 100 т	Силос для привозного заполнителя емкостью 100 т
Computer control system	Computer control system	Computer control system	Computer control system
Steel foundations	Steel foundations	Steel foundations	Steel foundations

Simple and modular construction, ensuring quick & easy set-up
Maximum versatility and flexibility by each batch
Wide range of optional equipment, including RAP/Hot RAP, SMA or VIATOP dosing systems
Eco-friendly pollution control system
Easy customization and installation of additional equipment
No concrete foundations required
Innovative screening drum design, reducing the heat lost in standard hot aggregate elevator
